APC SMT1500C uninterruptible power supply (UPS) Line-Interactive 1.44 kVA 1000 W 8 AC outlet(s)1

APC SMT1500C uninterruptible power supply (UPS) Line-Interactive 1.44 kVA 1000 W 8 AC outlet(s)2

APC SMT1500C uninterruptible power supply (UPS) Line-Interactive 1.44 kVA 1000 W 8 AC outlet(s)

APC SMT1500C. UPS topology: Line-Interactive, Output power capacity: 1.44 kVA, Output power: 1000 W. AC outlet types: NEMA 5-15R, AC outlets quantity: 8 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery life (max): 5 year(s), Battery recharge time: 3 h. Form factor: Tower, Product color: Black, Cable length: 72" (1.83 m). Width: 6.73" (171 mm), Depth: 17.3" (439 mm), Height: 8.62" (219 mm)

Manufacturer: APC

SKU: 5037946

Manufacturer part number: SMT1500C

GTIN: 0731304322795

Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.

Cold-start capable
Provides temporary battery power when the utility power is out.

Energy meter
Provides actual kilowatt hours of usage for energy conscious users.

Green mode
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.

High online efficiency
Reduces utlility costs, generates less heat.

Intuitive LCD interface
Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.

Predictive replace battery date
Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.

Pure sine wave output on battery
Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.

Single switched outlet group
Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.

SmartSlot
Customize UPS capabilities with management cards.

Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.

Products specifications

Attribute name	Attribute value
Response Time	10 ms
Width	6.73"
Depth	17.3"
Height	8.62"
Weight	54.2 lbs
Battery Recharge Time	3 h
Input Frequency	50/60 Hz
Display	LCD
Cable Length	72"
Display Type	LCD
Battery life (max)	5 year(s)
UPS topology	Line-Interactive
Automatic Voltage Regulation (AVR)	Yes
Automatic battery test	Yes
Serial interface	Yes
EMI/RFI noise filtering	Yes
Cold start	Yes
Harmonized System (HS) code	85078000
Software CD	Yes
Auto-restart	Yes
SmartSlot	Yes
Resource CD	Yes
Compliance certificates	RoHS
Technical details
Product color	Black
Sustainability certificates	ENERGY STAR
Packaging data
Package width	13"
Package depth	23.2"
Package height	13"
Package weight	60 lbs
Ports & interfaces
AC outlets quantity	8 AC outlet(s)
AC outlet types	NEMA 5-15R
USB port	Yes
Design
Certification	REACH
Form factor	Tower
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95 %
Storage relative humidity (H-H)	0 - 95 %
Operating altitude	0 - 118110.2"
Non-operating altitude	0 - 590551.2"
Power
Output power capacity	1.44 kVA
Power protection features	Short circuit
Features
Output operation voltage (max)	127 V
LED indicators	Status
Output power	1000 W
Noise level	45 dB
Surge energy rating	680 J
Input operation voltage (min)	75 V
Input operation voltage (max)	154 V
Output operation voltage (min)	110 V
Waveform	Sine
Audible alarm modes	Alarm when on battery, Low battery alarm, Overload alarm
Audible alarm(s)	Yes
Other features
Number of batteries supported	1
Packaging content
Cables included	RS-232, USB cable
Battery
Battery technology	Sealed Lead Acid (VRLA)
Hot-swap battery	Yes
Management features
Web-based management	Yes
